Wall Pack Light – MWP17

Wall Pack Light – MWP17

Short Description:

A field-adjustable upgrade – allows field adjustment of Light throw, CCTs and Light output MWP17 series, a more flexible and powerful wall pack, Delivers superior performance in a traditional appearance while maximizing flexibility on field and distributor shelves. MWP17
uses high-quality borosilicate glass lenses combined with a high-efficiency light engine to provide high-quality lighting services. Available in 3 different sizes, it can meet the different lighting needs of customers and perfectly cover the ugly stains left by typical metal halides.







Features & Benefits:

  • UV stabilized polycarbonate and glass are both available for the optic lens.
  • Four adjustable Wattage levels available for each models.
  • Color Temperature adjustable: 3000K,4000K, 5000K.
  • 4 Optics Adjustable (0°/15°/30°/45°)
  • Universal 120-277VAC or 347-480VAC input voltage.
  • 0-10V dimming driver standard for 10% to 100% dimming
  • Emergency Battery option.
  • Operating perature is -40′℃ to 40′C产品认证图标_WP17




Product Detail

Download

Product Tags

Specification
Series No.
MWP17
Voltage
120-277 VAC
Light Source Type
LED chips
Color Temperature
3000K/4000K/5000K
Power
30W, 60W, 100W, 150W
Light Output
4500lm, 8900lm, 14000lm, 22000lm
UL listing
Wet location
Operating Temperature
-40°C to 40°C ( -40°F to 104°F )
Lifespan
50,000 hours
Warranty
5 year
Application
Pathway, Building entryways, Perimeter lighting
Mounting
Junction box or Wall mount
Accessory
Photocell - Button (Optional), Emergency Battery Backup,PIR Sensor,Bluetooth PIR Sensor
Dimensions
30W 12x7.7x7.1in
60W/100W 14.2x9.3x8.1in
150W 18x9.75x9.27in

  • LED Wall Pack Light Specification Sheet
