Linear High Bay – MLH09

Short Description:

The linear elevated MLH09 series offers remarkable versatility and
cost – effectiveness. It effectively cuts contractor budgets and substantially reduces inventory space. This series retains the CCT (color temperature), watt – selectable features, and optical lens replacement
technology of the previous generation while upgrading its appearance for an enhanced visual experience. With three types of optical lenses -
prism diffuser, channel optics, and narrow optics – it can fully meet diverse lighting requirements and optimize lighting effects.

Features & Benefits:

• Has cast construction for durability. Tool - free optical switching and contractor - friendly packaging cut costs and speed installation.
• Offers 2 CCTs (4000K, 5000K), 2400 - 60000 lumens, up to 154 lm/W, and a lens for light control.
• With 120 - 277VAC/277 - 480VAC input, adjustable wattage, 0 - 10V dimming, PF > 0.9, THD < 20%,

               and 6KV surge protection, operates in -40°C to 50°C.

• Optional PIR or Bluetooth sensors and emergency battery available. Standard sensor receptacle enables quick

              on - site sensor installation for energy savings.

• Has an estimated 50,000 - hour lifespan, 5 - year limited warranty, is UL cUL damp location listed, and suits commercial and institutional spaces.
