LED High Bay – MHB16

Short Description:

A cost-effective UFO High Bay that fits within your budget, excelling in both performance and aesthetics, while offering strong adaptability to various environments with its exquisite profile. This compact and lightweight fixture is designed for exceptional durability and practicality, capable of replacing a 1000W MH. The MHB13 is an ideal choice for illuminating factories, warehouses, gymnasiums, and other outdoor areas.

Send email to us

Product Detail

Download

Product Tags

Specification
Series No.	MHB16
Voltage	120-277V or 277-480V
Dimmable	0-10V dimming
Light Source Type	LED chips
Color Temperature	3000K/4000K/5000K
Beam Angle	70°, 90°, 110°
Power	150W, 200W, 240W
Light Output	24000lm, 30000lm, 36000lm
UL listing	UL-US-2301661-3
Operating Temperature	-40°C to 50°C(-40°F -+ 122°F),-40°C to 55°C (-40°F -+ 131°F)
Lifespan	50,000 hours
Warranty	5 year
Application	Warehouses, Industrial, Retail
Mounting	Hanging Ring Mount，Conduit Pendant Mount，U-Bracket Mount
Accessory	Emergency Battery, Plug-in PIR sensor, U-Bracket
Dimensions
150W	Ø12.3 in x 6.26 in
200W	Ø14.18 in x 6.28 in
240W	Ø15.5 in x 6.4in
