LED Area Light – MAL09

Short Description:

Utilizing the latest LED technology, the MAL09 delivers high performance, high efficiency and long life while meeting the needs of low-budget
customers.The MAL09 retains the common NEMA photocell and sensor functionality, while also supporting adjustable power and color temperature
(power adjustments: 100%, 80%, 60%, 40%); (color temperature adjustments: 3000K, 4000K, 5000K). which helps to reduce customers’ inventory
pressure.

Send email to us

Product Detail

Download

Product Tags

Specification
Series No.	MAL09
Voltage	120-277 VAC or 347-480 VAC
Dimmable	0-10V dimming
Light Source Type	LED chips
Color Temperature	3000K/4000K/5000K
Power	100W, 160W, 270W, 330W
Light Output	15800 lm, 25,000 lm, 43500 lm, 50000 lm
Operating Temperature	-40°C to 50°C ( -40°F to 122°F )
Lifespan	100,000 hours
Warranty	5 year
Application	Automobile dealerships， Parking lots， Downtown areas
Mounting	Round pole, Square pole, Slipfitter, Wall mount and Yoke mount
Accessory	PIR Sensor， Photocell，External Glare Shield
Dimensions
100W/160W (Adjustable Square Mount)	22.6x13x5.4in
100W/160W (Slipfitter Mount)	22.6x13x2.5in
100W/160W (Wall Mount)	18.3x13.1x8in
100W/160W (Pole Mount)	18.3x13.1x8in
100W/160W (Yoke Mount)	19.7x13.1x2.5in
270W/330W (Adjustable Square Mount)	28x13x5.4in
270W/330W (Slipfitter Mount)	28x13x2.5in
270W/330W (Wall Mount)	24x13x8in
270W/330W (Pole Mount)	23.8x13x8in
270W/330W (Yoke Mount)	25.2x13.1x2.5in
