LED High Bay – MHB10

LED High Bay – MHB10

Short Description:

MHB10 continues the compact design concept of its predecessor, MHB08, making full use of LED technology and excellent heat dissipation management. While ensuring product versatility and high quality, MHB10 also reduces budget costs. MHB10 is a rare  circular high bay with DIP switches on the surface of the luminaire, supporting on-site adjustment of light output and color temperature without the need for any disassembly. The adjustment can be easily completed by simply flipping the DIP switches, greatly enhancing

product flexibility and convenience


Product Detail

Download

Product Tags

Specification
Series No.
MHB10
Voltage
120-277V or 120-347VAC or 347/480V
Dimmable
0-10V dimming
Light Source Type
LED chips
Color Temperature
3000K/4000K/5000K
Power
 160W, 205W
Light Output
27500 lm, 31000 lm
UL listing
UL-US-2353780-0
IP Rating
IP65
Operating Temperature
-40°C to 50°C ( -40°F to 122°F )
Lifespan
50,000 hours
Warranty
5 year
Application
Warehouses, Industrial, Retail
Mounting
Hook mount, Pendant mount and surface mounting
Accessory
Emergency Battery, External PIR sensor, U-Bracket
Dimensions
160W
Ø11inx7.3in
205W
Ø12inx7.5in



HB10-01


  • LED High Bay Light Specification Sheet
  • LED High Bay Light Instruction Guide
  • LED High Bay Light Sell Sheet
