Canopy Light – MCP07

Canopy Light – MCP07

Short Description:

MCP07 is a budget-friendly and energy-efficient fixture suitable for outdoors such as commercial buildings, building entrances, sidewalks and indoor parking lots. The uniquely designed translucent polycarbonate lens creates a comfortable lighting effect. At the same time, it is a fixture with high return on the basis of field regulation of the output lumen value (100%, 80%, 60%, 40%) and CCT (3000K, 4000K, 5000K). The MCP07 is also easy to install and compatible with Motion sensor and emerge battery features.
Features & Benefits:
  • Full die-cast for simplicity looks and enhanced life-span and durability
  • Two sizes and Multiple Outputs.
  • Color Temperature adjustable: 3000K, 4000K, 5000K.
  • Four adjustable Wattage levels available for each model.
  • 0-10V dimming driver standard for 10% to 100% dimming
  • Dusk-to-Dawn Photocell optional.
  • 6KV surge protection.
  • Operating temperature is -40°Cto 40°C.产品认证图标_CP03 CP07

Product Detail

Download

Product Tags

Specification
Series No.
MCP07
Voltage
120-277VAC or 120-347VAC
Dimmable
0-10V dimming
Light Source Type
LED chips
Color Temperature
3000K/4000K/5000K
Power
60W
Light Output
8400 lm
UL listing
UL-CA-2235953-0
Operating Temperature
-40°C to 40°C(-40°F to 104°F)
Lifespan
50,000 hours
Warranty
5 year
Application
Retail and grocery, Parking structures, Walkways
Mounting
Conduit pendant or surface mounting
Accessory
Sensor - Screw on (Optional), Emergency Box (Optional)
Dimensions
25W&36W&48W&60W
Ø9.5x3.0in

  • LED Canopy Light Specification Sheet
  • LED Canopy Light Instruction Guide
  • LED Canopy Light IES Files
